The best COB Solution in the market.
Models Available
P0.7 | P0.9 | P1.2 | P1.5 | P1.9 | P2.5
Features
Viewing quality
Reduces the moiré effect
Hi refresh controller up to 3840hz combined with our special coating in the led tile allows us to deliver a unique display with NO moiré effect for the best viewing experience.
With a stunning Hi Contrast display Ideal for TV Studio or Hi-End BoardRoom, our COB with mate finishing tile will deliver stunning images every time.
HI REFRESH CONTROLLER
3840hz
Shockproof & Waterproof
Waterproof
IP54
Shock Proof
IK7
Matte Surface
Antireflect
Better color texture
CLC technology does not require reflow welding. The epoxy resin prevents damage by contact in the diodes, gives a level of protection IP54 Generating resistance to impact, water, and reducing the chances of dead spots appear
The range of
colors
achieved is
10% higher
Color
26.000:1
contrast
ratio
Smoother and more vivid images
Contrast
179° both
vertically / horizontally
Without any color deviations
Angle of vision
Alloy Cabinet
Better heat dissipation prolonging screen’s life
The cabinet is made of a high resistance alloy, with electromagnetic insulating properties and high thermal conductivity. Optimized internal circuit to prevent module temperatures from rising.
Integrates the electrical and data connectors, so the connections are fast and without external cables.
Dot by dot calibration
Uniformity
up to 97% on
the entire
screen after
calibration
Its point-to-point calibration system records the initial color and light intensity values of each pixel.
Adjusting both in each of the primary colors (RGB) independently.
it is suitable for close viewing for long periods of time
Luminance
change rate
of CLC
Technical parameters
Module Parameters
Pixel Pitch 0.79 mm
LED type Flip Chip COB
Module resolution 192 x 144
Cabinet Specifications
Cabinet sizes (W x H x D) 609.6 x 342.9 x 59.7 mm
Cabinet Materials Die-Casting aluminium
Technical Specifications
Brightness 600 – 1,200 nits
Viewing Angle 179°V – 179°H
Refresh Rate 3,840 Mhz
Ecoative Features
Nox & Sox Abatement 50.03%
Certification of pollution abetment ISO 22197 from Fraunhofer Institut
Antidust Yes
Self-cleaning Yes
Module Parameters
Pixel Pitch 0.95 mm
LED type Flip Chip COB
Module resolution 160 x 120
Cabinet Specifications
Cabinet sizes (W x H x D) 609.6 x 342.9 x 59.7 mm
Cabinet Materials Die-Casting aluminium
Technical Specifications
Brightness 600 – 1,200 nits
Viewing Angle 179°V – 179°H
Refresh Rate 3,840 Mhz
Ecoative Features
Nox & Sox Abatement 50.03%
Certification of pollution abetment ISO 22197 from Fraunhofer Institut
Antidust Yes
Self-cleaning Yes
Module Parameters
Pixel Pitch 1.27 mm
LED type Flip Chip COB
Module resolution 128 x 96
Cabinet Specifications
Cabinet sizes (W x H x D) 609.6 x 342.9 x 59.7 mm
Cabinet Materials Die-Casting aluminium
Technical Specifications
Brightness 600 – 1,200 nits
Viewing Angle 179°V – 179°H
Refresh Rate 3,840 Mhz
Ecoative Features
Nox & Sox Abatement 50.03%
Certification of pollution abetment ISO 22197 from Fraunhofer Institut
Antidust Yes
Self-cleaning Yes
Module Parameters
Pixel Pitch 1,58 mm
LED type Flip Chip COB
Module resolution 96 x 72
Cabinet Specifications
Cabinet sizes (W x H x D) 609.6 x 342.9 x 59.7 mm
Cabinet Materials Die-Casting aluminium
Technical Specifications
Brightness 600 – 1,200 nits
Viewing Angle 179°V – 179°H
Refresh Rate 3,840 Mhz
Ecoative Features
Nox & Sox Abatement 50.03%
Certification of pollution abetment ISO 22197 from Fraunhofer Institut
Antidust Yes
Self-cleaning Yes
Module Parameters
Pixel Pitch 1.90 mm
LED type Flip Chip COB
Module resolution 80 x 60
Cabinet Specifications
Cabinet sizes (W x H x D) 609.6 x 342.9 x 59.7 mm
Cabinet Materials Die-Casting aluminium
Technical Specifications
Brightness 600 – 1,200 nits
Viewing Angle 179°V – 179°H
Refresh Rate 3,840 Mhz
Ecoative Features
Nox & Sox Abatement 50.03%
Certification of pollution abetment ISO 22197 from Fraunhofer Institut
Antidust Yes
Self-cleaning Yes
Module Parameters
Pixel Pitch 2.54 mm
LED type Flip Chip COB
Module resolution 60 x 45
Cabinet Specifications
Cabinet sizes (W x H x D) 609.6 x 342.9 x 59.7 mm
Cabinet Materials Die-Casting aluminium
Technical Specifications
Brightness 600 – 1,200 nits
Viewing Angle 179°V – 179°H
Refresh Rate 3,840 Mhz
Ecoative Features
Nox & Sox Abatement 50.03%
Certification of pollution abetment ISO 22197 from Fraunhofer Institut
Antidust Yes
Self-cleaning Yes
Main Applications
