See through in big format.
Technical parameters
Module Parameters
Pixel Pitch 15.6 x 15.6
LED type DIP 346-EPISTAR
Module resolution 64 x 2
Cabinet Specifications
Cabinet size (W x H) 500 x 1,000 mm
Cabinet Materials Aluminium
Technical Specifications
Brightness 12,000 nits
Viewing Angle 120°V – 120°H
Refresh Rate 3,840 Hz
Ecoative Features
Nox & Sox Abatement 50.03%
Certification of pollution abetment ISO 22197 from Fraunhofer Institut
Antidust Yes
Self-cleaning Yes
Module Parameters
Pixel Pitch 15.6 x 31.2
LED type DIP 346-EPISTAR
Module resolution 64 x 2
Cabinet Specifications
Cabinet size (W x H) 500 x 1,000 mm
Cabinet Materials Aluminium
Technical Specifications
Brightness 11,000 nits
Viewing Angle 120°V – 120°H
Refresh Rate 3,840 Mhz
Ecoative Features
Nox & Sox Abatement 50.03%
Certification of pollution abetment ISO 22197 from Fraunhofer Institut
Antidust Yes
Self-cleaning Yes
Module Parameters
Pixel Pitch 31.2 x 31.2
LED type DIP 346-EPISTAR
Module resolution 64 x 2
Cabinet Specifications
Cabinet size (W x H) 500 x 1,500 mm
Cabinet Materials Aluminium
Technical Specifications
Brightness 8,500 nits
Viewing Angle 120°V – 120°H
Refresh Rate 3,840 Mhz
Ecoative Features
Nox & Sox Abatement 50.03%
Certification of pollution abetment ISO 22197 from Fraunhofer Institut
Antidust Yes
Self-cleaning Yes
